| ΠΡΟΔΙΑΓΡΑΦΕΣ |
|---|
Technology | Dry Toner Electrophotography | Colour Resolution | CMYK, white (optional) | Tone Scale | Main scan: 1,200 dpi (3,600 dpi equivalent)Sub scan: 2,400 dpi (8 bit) | Paper Widths | 330 mm fixed (standard), 250 to 330 mm selectable(replacement of certain parts necessary) | Max. printed image width (length) | 320 mm (1,294 mm) | Media thickness (weight) | 76 to 270 μm (62 to 256 g/sqm) | Supported substrates | Paper, PP, PET (tack or non-tack, incl. textured paper, film etc.) | Printing speed | 39.9 m/min. (CMYK), down to 20 m/min. (CMYK+W),39.9, 34.2, 30, 20, 15 m/min. depending on media types | Machine dimensions (W x D x H) | 7,500 x 1,230 x 1,620 mm | Machine footprint (W x D) | 9,700 x 3,200 mm (incl. operating space) | Machine weight | 1,800 kg | Web control | Integrated web guide system (BST) on infeed section and rewinder | Max. roll diameter | 800 mm (unwinder and rewinder) | Shaft diameter | 3 inches (76 mm) | Konica Minolta Controller | IC-611 | Kodak (Creo) Controller, optional | IC-320L | Print engine | 3x 200-240 V, 25 A, 1-phase, 50-60 Hz | ICCU | 1x 200-240 V, 3 A, 1-phase, 50-60 Hz | Winders | 1x 200-240 V, 32 A, 1-phase 50-60 Hz (incl. 300 mA RCCB, Type A) | Compressed air | 6 bar, min. 20 l/min., 8 mm tube diameter |
|
